◆ AI Smart Analysis Function:
Area Intrusion, Absent Alarm, Loitering Detection, Line Crossing,
Retrograde Detection, Vehicle Illegal Parking, Human Detection;
◆ Up to 4K/8MP resolution; S265/H265/H264 Compression;
◆ Built-in Microphone & Speaker; 2-way audio;
◆ Built-in PoE;
◆ S265 compression to save bandwidth and storage space;
◆ Support Smart IR to avoid Infrared over-exposure at night;
◆ Support ICR auto switch, perfect D&N surveillance;
◆ Support 3D DNR and digital WDR;
◆ Support auto-electronic shuttle to suit different environment
◆ Support Onvif, email, NTP service
◆ AI Smart Analysis Function:
Area Intrusion, Absent Alarm, Loitering Detection, Line Crossing,
Retrograde Detection, Vehicle Illegal Parking, Human Detection;
◆ Up to 4K/8MP resolution; S265/H265/H264 Compression;
◆ Built-in Microphone & Speaker; 2-way audio;
◆ Built-in PoE;
◆ S265 compression to save bandwidth and storage space;
◆ Support Smart IR to avoid Infrared over-exposure at night;
◆ Support ICR auto switch, perfect D&N surveillance;
◆ Support 3D DNR and digital WDR;
◆ Support auto-electronic shuttle to suit different environment
◆ Support Onvif, email, NTP service
Specification | ||||
Model# | TG-IP311B-S4M | TG-IP311B-S6M | TG-IP311B-S6M-WDR | TG-IP311B-S8M |
DSP | T41NQ | T41NQ | T41NQ WDR | T41NQ |
Sensor | S82 | S6Y | S6H | S83 |
Main Stream | 4MP: 2560*1440@25fps; 3MP: 2048x1536@25fps; 2MP: 1920x1080@25fps | 6MP: 3072*2048@25fps; 5MP: 2592*1904@25fps; 4MP: 2560*1440@25fps; 3MP: 2048x1536@25fps; 2MP: 1920x1080@25fps | 6MP: 3072*2048@25fps; 5MP: 2592*1904@25fps; 4MP: 2560*1440@25fps; 3MP: 2048x1536@25fps; 2MP: 1920x1080@25fps | 8MP: 3840*2160@25fps; 6MP: 3072*2048@25fps; 5MP: 2592*1904@25fps; 4MP: 2560*1440@25fps; 3MP: 2048x1536@25fps; 2MP: 1920x1080@25fps |
Sub-Stream | Sub-code stream: D1 (720*576), VGA (640*360) | |||
Video Code Rate | Fixed bit rate, variable bit rate (Main stream: 160Kbps-4000kbps) | |||
Video Encoding | S.265 / H.265 / H.264 | |||
Video Type | Composited stream/video stream | |||
Audio Standard | G.711u / G.711A 8K 64bit | |||
Two-way-audio | Built-in with Mic & Speaker | |||
Lens | Motorized 2.7~13.5mm Zoom Lens | |||
IR LED | 8pcs dual-light LEDs; 30M (Full Color Night-vision option) | |||
IR LED Control | IR/warm/dual light, auto/manual/off, support 0-100 brightness adjust | |||
D-WDR | Off/Low/Middle/High | |||
3D DNR | Off/Low/Middle/High/Higher | |||
Defog | Off/Low/Middle/High | |||
Mirror | Off/ Horizontal Mirror/Vertical Mirror/180 degree flip | |||
Image Setting | Brightness, Contrast, Sharpness, Saturation, Chroma | |||
AI Samrt Analysis | ||||
Area Intrusion | * Support day arming /night arming mode; * Support to configure the customized arm time by week, with 4 time periods per day; * Support one detection area, and can draw a multi deformation detection area (consist of six points); * Support video stream overlay detection frame; * Support specified target type detection: human, motor vehicle (non motor vehicle also can be detected); * Linkage setting support: upload mail voice broadcast alarm alarm light; | |||
Line-Crossing | * Support day arming /night arming mode; * Support to configure the customized arm time by week, with 4 time periods per day; * Support one detection line, supports detection directions: A->B: ; * Support video stream overlay detection frame; * Support specified target type detection: human, motor vehicle (non motor vehicle also can be detected); * Linkage setting support: upload mail voice broadcast alarm alarm light; | |||
Loitering Detection | * Support day arming /night arming mode; * Support to configure the customized arm time by week, with 4 time periods per day; * Support one detection area, and can draw a multi deformation detection area (consist of six points); * Support video stream overlay detection frame; * Support Loitering time setting[10-3600]S; * Linkage setting support: upload mail voice broadcast alarm alarm light; | |||
Absent Alarm | * Support day arming /night arming mode; * Support to configure the customized arm time by week, with 4 time periods per day; * Support one detection area, and can draw a multi deformation detection area (consist of six points); * Support video stream overlay detection frame; * Support Loitering time setting[10-3600]S; * Support at least 1-3 people on duty; * Linkage setting support: upload mail voice broadcast alarm alarm light | |||
Vehicle Illegal Parking | * Support day arming /night arming mode; * Support to configure the customized arm time by week, with 4 time periods per day; * Support one detection area, and can draw a multi deformation detection area (consist of six points); * Support video stream overlay detection frame; * Support Loitering time setting[10-3600]S; * Linkage setting support: upload mail voice broadcast alarm alarm light; | |||
Vehicle Retrograde | * Support day arming /night arming mode; * Support to configure the customized arm time by week, with 4 time periods per day; * Support one detection area, and can draw a multi deformation detection area (consist of six points); * Support video stream overlay detection frame; * Supports Four detection directions, Detection line support B->A direction * Linkage setting support: upload mail voice broadcast alarm alarm light; | |||
Humanoid Detection | * Detect Quantity: ≤5 people humanoid; * Humanoid Size: Humanoid Pixel≥40X40; * Detection Ratio: ≥99%(meet above requirement); * Capture Speed: ≤1s; * Max Frame: 5fps/s; * Fault Ratio: ≤2%; * Detection Part: People with any posture including half body, head, hand, shoulder; * Detection Mode: Support static and dynamic humanoid detection; * Detection method: Support visible light image detection, and near infrared image detection; * Detection Area: Appointed area, default full-screen; * Trigger Method: Video trigger; | |||
Motion Detection | * Support day arming /night arming mode; * Support to configure the customized arm time by week, with 4 time periods per day; * Support full screen / area detection; * Linkage setting support: upload mail voice broadcast alarm alarm light; | |||
Privacy Mask | Support 4 areas | |||
Network Function | ||||
Protocol | TCP/IP,UDP,HTTP,HTTPS,DHCP,RTSP,DDNS,NTP,PPPOE,UPNP,SMTP | |||
Other Protocol | ONVIF | |||
Security Mode | Authorized username/password, HTTPS & AES connecting with password, RTSP verification | |||
Event Linkage | Upload Email/ FTP upload picture; Arming time support day arming/ night arming /customized arming | |||
Abnormal Inspection | Support disconnection alarm, IP conflict alarm, illegal access alarm | |||
Mobile Surveillance | P2P Cloud ; Phone App: SeeEasy (iOS, Android); | |||
Overlay(OSD) | Support time OSD/Title OSD, multi-line OSD (two lines); Main stream font support 12-60pt, sub stream font support 12-36pt, | |||
System Upgrade | Support Web upgrade | |||
Port | ||||
Alarm | N/A | |||
Card Slot | N/A | |||
Reset | N/A | |||
Network Port | RJ45 10M / 100M self-adaptive Ethernet port | |||
PoE | IEEE802.3af (optional) | |||
General | ||||
Power Supply | DC12V /POE | |||
Working Temp | -10°C ~ 50°C | |||
Working Humidity | 0﹪~90﹪ |
